Dual Phase Steel 2507 Thickening Centrifuge For Trisodium Phosphate
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | LLWZ900 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 80 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| Features: | Automatic Working, Saving Labor | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
|---|---|---|---|
| Centrifugal Type: | Screen Worm Centrifuge | Discharge: | Scroll Discharge |
| Machine Control: | PLC Control | Rotating Speed Control: | Frequency Converter |
| Key Selling Points: | Highly Efficient | Application: | Chemical & Medicine |
| High Light: | Steel 2507 Thickening Centrifuge,Steel 2507 industrial centrifuge machine,Thickening Centrifuge Trisodium Phosphate |
||
Product Description
LLWZ900 Thickening Dual Phase Steel 2507 Screen Worm Dewatering Separation Equipment Used For Trisodium Phosphate
Product Introduction
It is a combination of a solid bowl decanter centrifuge and a screen worm centrifuge with exceptional dewatering results.
In the decanter component, the feed suspension is first pre-thickened, i.e. it is extensively dewatered in the conical part of the solid bowl.
The liquid is clarified in the cylindrical part and finally discharged. The pre-thickened solids are transported into the cylindrical screen section by the worm where additional dewatering is achieved.
This centrifuge is particularly applicable for the solid-liquid separation in chemical, pharmaceutical and other industries. It features large processing capacity and low moisture rate of solid content. Especially for conditions that mother liquid with low solid concentration or mother liquid with small amount of oil substance, with better effect.
LLWZ Thickening Screen Worm Centrifuge
Technical Parameters
| Model | Bowl Diameter (mm) | Speed (r/min) | Separation Factor | Capacity(m³/h) | Power of Driving Motor (kW) | Weight (kg) | Dimension (L×W×H) (mm) |
| LLWZ900 | 900 | 1200 | 725 | 10-25 | 75 | 6500 | 3000*2200*2000 |
Technological innovation
In recent years, Huada has developed a number of new product and new technologies:
- Vertical bag-pulling bottom discharge centrifuge obtaining national invention patent
- Horizontal thickening and filtration centrifuge
- Intelligent remote control system technology
- Residual filter cake removal technology
- CIP technology
- Centrifuge explosion-proof application technology
- New generation of inert gas protection (explosion-proof) device
- Sludge dewatering and drying system
- Filtration and separation process design and supporting technology
- Drilling mud separation process technology
We don't just satisfy that the centrifuges can meet the separation requirements, but we pay more attention to other issues of how to reduce materials remained in the machines, increase processing output, reduce damage to the solid particles, lower energy consumption, reduce maintenance costs, improve working environment and reliability.
We conduct research and development of system integration technology and intelligent control technology, to provide customers with separation machinery and equipment which is safer, more intelligent, better in performance, environment-friendly and energy saving.
As a member of technical committee for standardization for China’s separation machinery, we have held revision of several industrial standards: GB/T 19815 Centrifuge Safety Requirements, JB/T 10769.1－2007 Types and Basic parameters of Three-column and plate Centrifuges, JB/T 8652－2008 Spiral Discharge Filtering Centrifuges and JB/T 5284-2010 Explosion-proof Peeler Centrifuge.
In 1998. our products passed national machinery safety certification, and reexamination is conducted each year. We have undertaken a number of national torch plan projects, key new product, technology-based small and mid-sized enterprise innovation fund projects. The accumulation of continuous research and development and application technology, become the industry benchmark.
We are becoming industrial benchmark through continuous research and development and accumulation of application technologies.
Profession makes trust!
