30/37kw Automatic Bottom Discharge Sugar Separating Centrifugal Machines With Bag-Pulling
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015, 01418P10003R2M |
| Model Number: | PLD1400 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD30000-110000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 60 work days |
| Payment Terms: | T/T, L/C, , Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Scraper Centrifuge |
|---|---|---|---|
| Diacharge: | Scraper Bottom Discharge With Bag Pulling | Operate: | Automatic Batch Operate |
| Max. Capacity(kg): | 700 | Screen Touch: | Optional |
| Speed Control: | Frequency Converter | Motor Power(kw): | 30/37 |
| Max. Separation Factor: | 700/1036 | Application: | Industrial Centrifuge |
Product Description
PQLD Pharma Centrifuges
The product is designed with an overall turnover cover, and the transition of the whole structure is smooth and flat, which can give a thorough cleaning, effectively putting an end to the dead corners and can remove online residuals to avoid cross-contamination of materials. It is suitable for material separation requiring high purity and hygiene.
Technical Parameters
| Items | Model | |
| PLD1400 | ||
| Basket Diameter(mm) | 1400 | |
| Effective Basket Height(mm) | 800 | |
| Basket Volume(L) | 600 | |
| Max. Capacity(kg) | 700 | |
| Motor Power(kw) | 30/37 | |
| Max. Speed(r/min) | 950/1150 | |
| Max. Separation Factor | 700/1036 | |
| Weight(kg) | Platform construction | 9000 |
| Square box structure | ||
The materials to be separated are normally corrosive. So for safety, the parts in contact with these corrosive materials must be anti-corrosive.
Material of constructions: 304, 321, 316L, 904L, TA, 2205, 2507etc.
When there is determined application experience or corrosion data, carry out coupon test and laboratory verification to ensure selected material meet anti-corrosion requirements.
Surface anti-corrosion treatment: PE lined, rubber lined and halar lined and F40, F46, PFA etc.
Anti-corrosion requirements of sealing elements can not be neglected; material of sealing elements shall ensure prevention against corrosion from acids, alkali and solvents.
The customer shall forward the physical and chemical properties of the material and washing liquid (chemical properties and separation temperature etc.) to the manufacturer so that it can make recommendations for centrifuge materials based on characteristics of the separation medium, and that the suitable seal ring, seal washer and filter cloth can be provided, thus ensuring anti-corrosion requirements on the centrifuge.
Found in 1993, Jiangsu Huada Centrifuge Co., Ltd. is located at Zhangjiagang City, an emerging port city in China, which is situated in China’s most economically advanced Yangtze River Delta region, with convenient traffic and beautiful environment.
Over 20 years. Huada had always been being devoted to research and development, production and marketing of filtration and separation machinery. With technical innovation as driving force of the enterprise to participate in market competition, we have developed series of centrifuges with high technical content, to meet the market demand; to gain the market by serving customers, we have accumulated extensive experience in application through years of technical research and development and sales application and can provide perfect pre-sale, sale and after-sale service; we ensure product quality with lean management and improve product reliability.
Huada is a member of Technical Committee for Standardization of Chinese Separation Machinery, a vice president of Separation Machinery Branch of China General Machinery Association, a drafter of national and industrial standards on centrifuges, a high-tech enterprise in Jiangsu Province and a key high-tech enterprise for national torch plan. In 1998, our centrifuges acquired national safety certification.
Huada is one of enterprises in domestic filtration and separation machinery industry which is the largest in scale, the most complete in product varieties and series, the most competitive and the most influential.
Huada has a large number of engineers and technical personnel who account for over one third of total number of employee. It owns an engineering technology research center of Jiangsu Province and establishes multiple professional teams of technical research and development, technical application, process design, inspection and testing, lean production management, etc. and we have made great achievements. We have successfully developed multiple new products and technologies having proprietary intellectual property rights and, national invention patent which include vertical pull-bag automatic discharge centrifuges, horizontal preconcentration filtering centrifuge, intelligent remote control system technology and so on, as well as obtained good market application; we have resolved difficult problems on filtration and separation for users.
By using our experience, for customers personalized requirements, we can design practical and feasible technical schemes on separation tailored for customers; also, full consideration is given to improvement of working environment. Design idea of automation and humanization is always implemented in the process of design and manufacturing. We believe that we are not only stronger than others to some extent in terms of service, quality and reliability, but more importantly we are good at listening to opinions of customers.
We are in favour of an important principle: ”Open to customers”. We carry out optimum design and modular design of centrifuges, to improve the versatility of parts and to facilitate industrialized production; establish parts processing line and assembly line with professional division of labor and process refinement, mould, NC processing technology, etc according to process characteristics; and establish lean production management system, to ensure product quality and production cycle.
