3600rpm 3 Phase Automatic Decanter Centrifuges For Processing Limed Fleshings
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | LWS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD40000-150000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 50 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Decanter Centrifuge |
|---|---|---|---|
| Discharge: | Scroll Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Automatic Continuous Operation | Bearing: | NSK Or SKF |
| Explosion-proof System: | Optional | ||
| High Light: | 3600rpm Automatic Decanter Centrifuges,3600rpm 3 phase centrifuge,Decanter Centrifuges 420mm |
||
Product Description
LWS 3-Phase Automatic Working Saving Labor Easy To Operate Decanter Centrifuges Used For Processing Limed Fleshings
Description
LWS series three phase decant centrifuge is used for solid-liquid-liquid separation, namely one kind of solid phase (with largest specific gravity ) and two kind of immiscible liquid phase with different density. The conveyor rotates in the same direction as the bowl, but at a different speed, the material is fed into the bowl through a stationary feed pipe. Centrifugal forces cause instant sedimentation of the solids on the wall of the bowl, while two liquid phases forming light liquid phase layer and heavy liquid phase layer. Scroll conveys the solids towards the conical end of the bow, and out of centrifuge from solid discharge port. The light liquid phase then is discharged out continuously through the overflow port at the large end of the bowl, and the heavy liquid phase will be discharged out through the centrifugal pump large end of the bowl, thus realizing the three-phase separation.
Technical Parameters
| Model | Bowl Diameter (mm) | L/D | Bowl Speed (r/min) | Separation Factor | Power of Driving Motor (kW) | Weight (kg) | Dimension (L×W×H) (mm) |
| LWS355*1460 | 350 | 4.17 | 4000 | 3130 | 22-30 | 2200 | 3450*1010*1030 |
| LWS420*1680 | 420 | 4 | 3600 | 3050 | 30-37 | 4000 | 3500*1450*1300 |
| LWS530*2120 | 530 | 4 | 3200 | 3040 | 45-55 | 5500 | 4100*1600*1450 |
| LWS720*2880 | 720 | 4 | 2000 | 1610 | 110 | 11000 | 5300*2050*1750 |
Company profile
Huada currently has two production bases, covers floor area of 100000 square meters and plan area of 45000 square meters, as well as owns more than 500 sets of various mechanical processing equipment among which there are over 50 sets of numerical control equipment and more than 100 sets of various testing equipment.
Due to the working characteristic of centrifuges, customers attach great importance to safety of centrifuges in use.
As a manufacturer, we do not dare to take it lightly. Centrifuge safety performance is fully controlled in the process of design and manufacture. Each link in design calculation, production process control, test and inspection operates as per procedure to minimize remaining risk.
Our business philosophy is scientific and reasonable design, more perfect manufacturing, professional and standard service. We will provide service to our customers with constant technical innovation, perfect products and professional experience in application.
In 2015, Huada become a wholly-owned holding company of Scimee Sci.& Tech. Co., Ltd.
As a public company, Huada will gain greater market development opportunities, more human resources and scientific research investment, more standardized management and better development on the platform of Scimee.
Scimee Sci.& Tech. Co., Ltd. (stock abbreviation: Scimee. Stock code: 300425) focuses on development and application of magnetic separation water purification technology and is the largest domestic magnetic separation water purification equipment manufacturing enterprise.
Based on magnetic separation water purification technology, in light of biochemical treatment technology, biological- ecological water repair technology, membrane technology and other applicable technology in sewage treatment area, our business covers the whole process of integrated services of industrial and municipal water treatment project including investment and financing, consulting assessment, scheme design, equipment integration, construction and operation management and we become a provider of whole water treatment solution and comprehensive environmental services.
