Flottweg Tricanter Impeller Liquid Discharge 3600rpm Decanter Centrifuges SKF Bearing
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | LWS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD40000-150000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 70 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Decanter Centrifuge |
|---|---|---|---|
| Discharge: | Scroll Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Automatic Continuous Operation | Explosion-proof System: | Optional |
| High Light: | 3600rpm Decanter Centrifuges,3600rpm horizontal centrifuge,Decanter Centrifuges SKF Bearing |
||
Product Description
LWS Using SKF Bearing Horizontal Flottweg Tricanter - Impeller Liquid Discharge
Materials
The bowl, conveyor, inlet tube, outlets, cover and other parts in direct contact with the process media are all made of stainless steel. The discharge ports, conveyor flights and feed zone are protected with materials that are highly resistant to erosion. The frame is made of mild steel with an epoxy enamel finish.
Technical Parameters
| Model | Bowl Diameter (mm) | L/D | Bowl Speed (r/min) | Separation Factor | Power of Driving Motor (kW) | Weight (kg) | Dimension (L×W×H) (mm) |
| LWS355*1460 | 350 | 4.17 | 4000 | 3130 | 22-30 | 2200 | 3450*1010*1030 |
| LWS420*1680 | 420 | 4 | 3600 | 3050 | 30-37 | 4000 | 3500*1450*1300 |
| LWS530*2120 | 530 | 4 | 3200 | 3040 | 45-55 | 5500 | 4100*1600*1450 |
| LWS720*2880 | 720 | 4 | 2000 | 1610 | 110 | 11000 | 5300*2050*1750 |
* All parts coming into contact with the product are made of stainless steel.
* 3-phase AC motor for controlled torque starting via frequency converter
* Approximately 80 to 90 % of the oil is recovered.
* Low personnel costs due to continuous and automatic operation.
* Highest g-force for higher solids output
* Adjustable bowl speed via VFD
* Automatic adjustment of differential speed via VFD
* Two motor drive
* Belts for both primary motor and secondary motorFeatures
* All parts coming into contact with the product are made of stainless steel.
* 3-phase AC motor for controlled torque starting via frequency converter
* Approximately 80 to 90 % of the oil is recovered.
* Low personnel costs due to continuous and automatic operation.
* Highest g-force for higher solids output
* Adjustable bowl speed via VFD
* Automatic adjustment of differential speed via VFD
* Two motor drive
* Belts for both primary motor and secondary motor
Technological innovation
Focus – Huada focuses on research and development, manufacture and application of filtration and separation technology.
Leading - Becoming industrial benchmark through continuous research and development and accumulation of application technologies
In recent years, Huada has developed a number of new product and new technologies:
- Vertical bag-pulling bottom discharge centrifuge obtaining national invention patent
- Horizontal thickening and filtration centrifuge
- Intelligent remote control system technology
- Residual filter cake removal technology
- CIP technology
- Centrifuge explosion-proof application technology
- New generation of inert gas protection (explosion-proof) device
- Sludge dewatering and drying system
- Filtration and separation process design and supporting technology
- Drilling mud separation process technology
We don't just satisfy that the centrifuges can meet the separation requirements, but we pay more attention to other issues of how to reduce materials remained in the machines, increase processing output, reduce damage to the solid particles, lower energy consumption, reduce maintenance costs, improve working environment and reliability.
We conduct research and development of system integration technology and intelligent control technology, to provide customers with separation machinery and equipment which is safer, more intelligent, better in performance, environment-friendly and energy saving.
