Olive Oil Small Decanter Centrifuges 350mm Horizontal Three Phase
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | LWS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD40000-150000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 50 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Decanter Centrifuge |
|---|---|---|---|
| Discharge: | Scroll Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Automatic Continuous Operation | Explosion-proof System: | Optional |
| High Light: | Decanter Centrifuges 350mm,Olive Oil Centrifuge Three Phase,Olive Oil Small Decanter Centrifuges |
||
Product Description
LWS Model Customized New Horizontal Three-Phase Olive Oil Small Decanter Centrifuge
Applications
The decanter centrifuge is a continuously operating horizontal solid wall centrifuge for olive oil extractions. It is the ideal for olive oil recovery processing.
The olive oil decanter centrifuge separates the olive pulp into the fruit pulp, oil and water phases. In downstream, the separator purifies the oil phase and removes ultrafine impurities. This process is gentle to the product and is appropriate for producing the highest grade of olive oil.
The feed suspension is introduced through an inlet pipe into the feed zone of the conveyor where it is accelerated and directed into the interior of the bowl. The settled solids are conveyed axially towards the small end of the bowl by means of the screw conveyor, which rotates at a slightly different speed than the bowl. On the way to the discharge ports the solids are lifted out of the pond up along the dry beach.
The solids are finally discharged from the bowl through the discharge ports into the collecting chamber of the casing that surrounds the bowl. From there the solids are removed by gravity through the outlet funnel. The liquid phase forming a hollow cylinder due to the centrifugal force, and flows towards the large end of the bowl. There the liquid overflows adjustable plate dams into the centrate chamber of the casing and is discharged by gravity.
Technical Parameters
| Model | Bowl Diameter (mm) | L/D | Bowl Speed (r/min) | Separation Factor | Power of Driving Motor (kW) | Weight (kg) | Dimension (L×W×H) (mm) |
| LWS355*1460 | 350 | 4.17 | 4000 | 3130 | 22-30 | 2200 | 3450*1010*1030 |
| LWS420*1680 | 420 | 4 | 3600 | 3050 | 30-37 | 4000 | 3500*1450*1300 |
| LWS530*2120 | 530 | 4 | 3200 | 3040 | 45-55 | 5500 | 4100*1600*1450 |
| LWS720*2880 | 720 | 4 | 2000 | 1610 | 110 | 11000 | 5300*2050*1750 |
Customers Are More at Ease with Guaranteed Services
- Improvement of Service Team - Making Services More Efficient
- Service capacity: 23 regular after-sales service employees + 7 emergency service employees + 15 mobile service employees, of which, those with service experience for more than 10 years account for 35%, those with service experience for 5-10 years account for 40%, and those with service experience for 3-5 years account for 25%.
- Service qualifications: A history of customer on-site services for nearly 30 years, experience in providing services to more than 5,000 customers, a total of more than 200,000 service times.
- Service results: Customer satisfaction of more than 95%.
- We only obtain information about the separation process within the scope of your permission and guarantee the security of your data.
- Establishment of Strategic Direction - Making Services More Reassuring
- Our mission is "to provide customers with high-tech centrifuges so that more people can enjoy perfect products and services in a convenient and intelligent way, and to grow into a provider of green industrial solutions based on high-end intelligent manufacturing". We have been adhering to the development concept of "service as the core and customer satisfaction as the purpose". Over the years, we have continuously improved company service management, service team building and service quality to provide customers with more professional and standardized services.
- Construction of After-sales Outlets - Making Services More Convenient
- Seven service outlets + one service center, realizing emergency service within 8h, inter-provincial service within 12h, and national service within 48h.
