Model Vertical Batch Operate After-sales Service Provided Centrifuge Bottom Discharge With Bag-Pulling For Food Industry
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015, 01418P10003R2M |
| Model Number: | PLD1670 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 80 work days |
| Payment Terms: | T/T, L/C, , Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Scraper Centrifuge |
|---|---|---|---|
| Diacharge: | Scraper Bottom Discharge With Bag Pulling | Operate: | Automatic Batch Operate |
| Control: | PLC Control | Max. Capacity(kg): | 1125 |
| Basket Volume(L): | 900 | MOC: | Stainless Steel |
| Weight(kg): | 12500 | Application: | Industrial Centrifuge |
Product Description
Main Features
- The basket is comprehensively machined and undergoes 100% weld flaw detection, with high machining precision and large filtering area, conducive to ultrafine particle filtration
- Quick filter bag replacement
- It is designed with a detachable basket lip, reliable self-locking, and scientific filter cloth fixed module (tensioning device + quick assembly structure), by which, the filter cloth can be replaced quickly.
- Fully enclosed structure: The material is completely separated from the transmission, which can protect the nitrogen filling inside the equipment, effectively prevent material from contamination, and ensure the safety of personnel.
- Uniform distribution: Streamline distributor can improve the distribution balance and reduce the distribution vibration for the material with poor fluidity.
- Multiple safety protection and guarantee
- It has multiple protections, including overvibration protection, overcurrent protection, temperature control protection, scraper in-situ position protection, scraper stroke protection, cap protection, interlock protection, scraper blocking protection, nitrogen protection, etc.
Technical Parameters
| Items | Model | |
| PLD1670 | ||
| Basket Diameter(mm) | 1670 | |
| Effective Basket Height(mm) | 920 | |
| Basket Volume(L) | 900 | |
| Max. Capacity(kg) | 1125 | |
| Motor Power(kw) | 45 | |
| Max. Speed(r/min) | 850 | |
| Max. Separation Factor | 675 | |
| Weight(kg) | Platform construction | 12500 |
| Square box structure | ||
TECHNOLOGICAL INNOVATION
Focus – Huada focuses on research and development, manufacture and application of filtration and separation technology.
Over 20 years , Huada Ltd. has been considering technological innovations as one of the corporate strategies. We have recruited a group of talented engineers and technicians professional in filtration and separation technology to research and develop the centrifuges with better separation efficiency, lower energy consumption, better convenient operation, higher reliability and closer focus on the separating materials. In addition , working environment, automation and individualization are always taken into account throughout the course of design and manufacturing we still keep continual summarizing our experience, and continually change and improve our design in order to optimize our products.
Professional - Establishing up professional teams on technology research and development , technology application , process design , inspection and tesing
Filtration and separation technique is a specialized technology, it takes quite long time from theory research, technical design, trial manufacturing, testing, approval to practical application. To a large extent, Huada benefits from “being advanced”. i.e. being more advanced than users and competitors in the same Industry. When users have higher requirements, we have already done some research or have better solutions. We deeply know that it is the most important matter to guarantee the safety of centrifuge, it is the base for trust and cooperation. By learning the advanced technology abroad Huada has been developing a number of patented new technologies. Currently, Huada has owned more than 100 patents. These technologies have been soon applied. We have formed a healthy cycle from R&D to marketing and innovation.
Separation technology is one of the most important steps in the process of industrial production. It is a vital step to separate solid matters from the liquid in numerous industrial productions. With the rapid development in chemistry and pharmacy, separation technology is improving as well and completely different from the simple and poor one in the past. It highly demands safety performance, the performance of separation, working environment, automation and reliability of the centrifuge, for instance, when it works in the environment with explosive-proof, tiny material separation, separation of highly adhesive materials, high purity demands, full automatic control, unmanned attention and remote monitoring. In response to the market and customers’ needs, our technicians will customize the design and separation techniques for customers. Meanwhile, when it comes to design and manufacturing,
As we are professional we can achieve your needs.
