Pull-Bag Saving Labor High Productivity Scraper Bottom Discharge Dewatering Centrifuge For Food Industry
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015, 01418P10003R2M |
| Model Number: | PLD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD30000-110000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 70 work days |
| Payment Terms: | T/T, L/C, , Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| Features: | Automatic Working, Saving Labor | Place Of Origin: | China |
|---|---|---|---|
| Voltage: | 220v/300v/380v/optional | Control System: | PLC Control |
| Condition: | New | Application: | Solid Liquid Separation, Dewatering |
| Type: | Separating Plant | Core Components: | PLC, Bearing, Motor |
| Key Selling Points: | High Productivity | Warranty: | 1 Year |
Product Description
Product Description
This solid-liquid separation centrifuge remains the main functions of LGZ series such as separation and scraper discharge. Our pharmaceutical centrifuge features pull action filter to offer more than 99% cake removal rate.
This food centrifuge bypasses batch cross among different products and the negative impacts on filtration efficiency caused by residual cale. Based on these advantages, our chemical centrifuge has been extensively applied to solid-liquid separations of crystallized materials for industries of pharmacy,food and chemical,etc.
Features
1.Adopt lid reversible structure or whole housing reversible structure,it is convenient for cleaning and maintenance.
2.Whole-sealing structure, inner machine, bearing seat, scraper are protected by nitrogen.
3. The tensity of polish is accurate, roughness of surface can reach Ra 0.2-0.4μm.
4.Structure is simple and seam is glazed, easy to clean.
5.The sealing of the main shaft is reliable and inspecting device is equipped, which can ensure no leaking.
6.CIP device is set reasonable, it can clean the centrifuge effectively with no cleaning angle.
7.Uperization is used in the machine.
8.Adopt frequency conversion controlling system, dynamic or regenerative braking.
9.Enclosed cover is set on the transmission device to avoid powder pollution during the process of transmission.
Technical Parameters
| Items | Model | |||||||
| PLD800 | PLD1000 | PLD1250 | PLD1400 | PLD1600 | PLD1670 | PLD1800 | ||
| Basket Diameter(mm) | 800 | 1000 | 1250 | 1400 | 1600 | 1670 | 1800 | |
| Effective Basket Height(mm) | 460 | 570 | 700 | 800 | 900 | 920 | 1100 | |
| Basket Volume(L) | 100 | 190 | 400 | 600 | 800/750 | 900 | 1250 | |
| Max. Capacity(kg) | 130 | 230 | 500 | 700 | 1000 | 1125 | 1500 | |
| Motor Power(kw) | 7.5/11 | 15 | 22 | 30/37 | 37/55 | 45 | 55 | |
| Max. Speed(r/min) | 1200/1500 | 1100/1200 | 1000/1200 | 950/1150 | 850/1050 | 850 | 800 | |
| Max. Separation Factor | 645/1007 | 678/805 | 700/1007 | 700/1036 | 647/987 | 675 | 645 | |
| Weight(kg) | Platform construction | 2000 | 3500 | 5000 | 9000 | 12000 | 12500 | 17000 |
| Square box structure | 4000 | 6000 | ||||||
