ISO9001 Plastic Lining Vertical Bottom Discharge Centrifuge For NH4 2SO4
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 01418P10003R2M |
| Model Number: | LGZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 80 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| MOC: | Stainless Steel | Core Components: | PLC, Bearing, Motor |
|---|---|---|---|
| Machine Control: | PLC Control | Operation Type: | Automatic Batch Centrifuge |
| Centrifugal Type: | Basket Centrifuge | Discharge Type: | Scraper Bottom Discharge |
| Key Selling Points: | Automation | Rotating Speed Control: | Frequency Converter |
| High Light: | Discharge Centrifuge NH4 2SO4,automatic batch centrifuge NH4 2SO4,ISO9001 Bottom Discharge Centrifuge |
||
Product Description
LGZ ISO9001 Plastic Lining Vertical Bottom Discharge Scraper Centrifuges Used For (NH4)2SO4
Product Description
Working Principle
LGZ centrifuge is a kind of vertical centrifuge with PLC control automatic filtration type and down scraping discharging, which adopts continuously running and intermittent discharge.
Centrifuge is semi-automatic centrifuge. Driven by the motor, the drum revolves step by step to the speed suitable for feeding, then the products which is to be separated enter to the revolving drum through feeding pipe. Centrifuge would stop feeding if the products' volume amounts reach to the predetermined date and the speed raises higher for separation. Suspension's separation can be made possible by filter cloth(or filter net)under the effect of centrifugal force.
Liquid phase is draught out through filter layer and thrown into the empty chamber and finally discharged from the liquid outlet while the solid phase reminds on the drum to from bucket-shaped filter cake which will be washed in the following steps. When filter cake meets the requirement of separation, centrifuge will be slowed down to the discharging speed. The scraper begins to take effect and scrape the filter cake from inner wall to the products outlet of centrifuge.
Technical Parameters
| Items | Models | ||||||
| LGZ800 | LGZ1000 | LGZ1250 | LGZ1400 | LGZ1600 | LGZ1800 | ||
| Basket Diameter(mm) | 800 | 1000 | 1250 | 1400 | 1600 | 1800 | |
| Effective Basket Height(mm) | 420 | 550 | 630/800 | 750 | 800/1000 | 1000 | |
| Basket Volume(L) | 100 | 190 | 400/500 | 600 | 800/1000 | 1250 | |
| Max. Capacity(kg) | 135 | 230 | 500/600 | 700 | 1000/1250 | 1500 | |
| Motor Power(kw) | 7.5/11 | 15 | 22/30 | 30/37 | 37/45 | 55 | |
| Max. Speed(r/min) | 1200/1500 | 1100/1200 | 1000/1200 | 950/1150 | 850 | 800 | |
| Max. Separation Factor | 645/1007 | 678/805 | 700/1007 | 700/1036 | 647 | 645 | |
| Weight(kg) | Platform construction | 2000 | 3500 | 5000 | 9000 | 12000 | 17000 |
| Square box structure | 4000 | 6000 | 13000 | ||||
Feature
1.Adopt lid reversible structure or whole housing reversible structure,it is convenient for cleaning and maintenance.
2.Whole-sealing structure, inner machine, bearing seat, scraper are protected by nitrogen.
3. The tensity of polish is accurate, roughness of surface can reach Ra 0.2-0.4μm.
4.Structure is simple and seam is glazed, easy to clean.
5.The sealing of the main shaft is reliable and inspecting device is equipped, which can ensure no leaking.
6.CIP device is set reasonable, it can clean the centrifuge effectively with no cleaning angle.
7.Uperization is used in the machine.
8.Adopt frequency conversion controlling system, dynamic or regenerative braking.
9.Enclosed cover is set on the transmission device to avoid powder pollution during the process of transmission.
LGZ/PGZ Series Automatic Bottom Discharging Scraper Centrifuge
Apply to separating the suspension containing partaining particles, but also fibers, but also fibers, especially the highly sticky, containing micro
particles. poisonous and flammable materials, like antibiotics, vitamins , and mineras . salts , goumet powders , foodstuff additives , amylum , sugar . chemical flavors , thiamin , plasters , Glauber’s salt , bluestone , potassium choride , borax . dyestuffs , pigment. Resin , pesticides , and environmental production .The centrifuge is highly automated, haslarge capacity and can be remote-controlled.
