Aluminium Hydroxide Separating 1400rpm 200L Top Discharge Centrifuge Rubber Lined
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 01418P10003R2M |
| Model Number: | PSD1000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 60 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Lifting Top Discharge | Machine Control: | PLC Control |
| Basket Volume(L): | 200 | Max. Capacity(kg): | 250 |
| Operate: | Manual Batch Operating | Effective Basket Height(mm): | 520 |
| High Light: | 200L Top Discharge Centrifuge,200L Basket Centrifuge,1400rpm Top Discharge Centrifuge |
||
Product Description
PSD Small Manual Aluminium Hydroxide Separating Stainless Steel Rubber Lined Basket Centrifuge With Bag-Lifting
Product Overview
Aided mechanical discharge is adopted for the PSD centrifuge.
Combining high efficiency of the automatic peeler centrifuge and wide application scope of the top discharge centrifuge, this product is advanced in structural design, small in floor covering area, low in failure rate and high in cost performance.
Technical Parameters
| Items | Models |
| PSD1000 | |
| Basket Diameter(mm) | 1000 |
| Effective Basket Height(mm) | 520 |
| Basket Volume(L) | 200 |
| Max. Capacity(kg) | 250 |
| Max. Speed(r/min) | 1200/1400 |
| Max. Separation Factor | 805/1096 |
| Motor Power(kw) | 11/15 |
| Dimension(mm) | 1970*1400*1500 |
| Weight(kg) | 2500/2700 |
Working Principle
Once the materials to be separated enter the fast-spinning basket, it will be filtrated by the filter liner under the centrifugal force. The liquid flows out through the liquid outlet, but solids deposit on the internal wall of the basket. Once the solid cake reaches the rate capacity, feeding stops. Wash the solids cake, and then drain out the washing water. Finally stop the machine. Use the lifting tool or crane to lift out the filter cloth with solid cake, and move to the discharging place. Open the filter cloth and discharge the solid cake. Put the filter cloth back to the centrifuge and move to next batch.
Scope of Application
This product can be used for the solid-liquid separation of suspensions containing solid particles, as well as for the solid-liquid separation of fibrous materials, such as gypsum, copper sulfate, potassium chloride, borax, dyes, pesticides, salt, monosodium glutamate, food additives, starch, sugar, chemical seasoners, antibiotics, vitamins, copper, zinc, aluminum and other minerals, metal refining, sludge treatment, and sewage treatment has been widely applied in the pharmaceutical, chemical, food, environmental protection, energy and other industries.
Product Features
• Low labor intensity and high efficiency: configured with a hydraulic cantilever crane for mechanical discharge.
• Grains less prone to breakage: special-purpose slings used to lift and discharge the materials as a whole.
• Stable operation: low gravity center of the equipment designed and liquid damping device adopted to attenuate vibration.
• Variable frequency control: stable startup and adjustable separation factor.
• Easy replacement of filter cloth: basket lip designed with special structure that can be disassembled fast.
• Optional configurations for the installation of cake layer control device, atomizing & washing pipe, CIP online cleaning system, explosion-proof sight glass with lamp, etc.
• Multiple safety protections: nitrogen protection system, overvibration protection, cover opening protection, overload protection, electromagnetic interlocking, etc.
• Cover opening mode: hydraulic drive and mechanical drive.
Technological innovation
Separation technology is one of the most important steps in the process of industrial production. It is a vital step to separate solid matters from the liquid in numerous industrial productions. With the rapid development in chemistry and pharmacy, separation technology is improving as well and completely different from the simple and poor one in the past.
It highly demands safety performance, the performance of separation, working environment, automation and reliability of the centrifuge, for instance, when it works in the environment with explosive-proof, tiny material separation, separation of highly adhesive materials, high purity demands, full automatic control, unmanned attention and remote monitoring.
In response to the market and customers’ needs, our technicians will customize the design and separation techniques for customers. Meanwhile, when it comes to design and manufacturing, as we are professional we can achieve your needs.
