Manual Vertical 320L 1000rpm Top Discharge Centrifuge For Chemical Flavors
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | PQFB1250 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 75 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Top Discharge | Max.: | 400 |
| Max. Separation Factor: | 700/1007 | Operate: | Manual Batch Operating |
| Motor Power(kw): | 18.5/22 | Weight(kg): | 4300 |
| High Light: | 1000rpm Top Discharge Centrifuge,320L manual centrifuge,Top Discharge Centrifuge Chemical Flavors |
||
Product Description
PQFB High Productivity Manual Operation Vertical Top Discharge Filter Centrifuges For Chemical Flavors
PQFB/PQSD series centrifuges are applicable to the solid-liquid separation in the clean areas with certain requirements for sanitation. Being aesthetic in appearance, high in manufacturing technology, stable in operation, easy in maintenance, and complying with the GMP standards and high requirements for sanitation, this product has been broadly applied in pharmaceutical production, food production and fine chemical engineering and other industries.
Technical Parameters
| Items | Models |
| PQFB1250 | |
| Basket Diameter(mm) | 1250 |
| Effective Basket Height(mm) | 485 |
| Basket Volume(L) | 320 |
| Max. Capacity(kg) | 400 |
| Max. Speed(r/min) | 1000/1200 |
| Max. Separation Factor | 700/1007 |
| Motor Power(kw) | 18.5/22 |
| Dimension(mm) | 2770*1800*1470 |
| Weight(kg) | 4300 |
Operating principle
Once the materials to be separated enter the fast-spinning basket, it will be filtrated by the filter liner under the centrifugal force. The liquid flows out through the liquid outlet, but solids deposit on the internal wall of the basket.
Once the solid cake reaches the rate capacity, feeding stops. Wash the solids cake, and then drain out the washing water. Finally stop the machine. The solid cake is discharged manually and move to next batch.
Main Configurations
- Electric configuration: PLC control, variable-frequency (VF) control, electric control cabinet (ordinary type and explosion-proof type), motor (ordinary type, explosion-proof type, VF type and energy saving type), field operation box (ordinary type and explosion-proof type). Nitrogen protection system, oxygen content detection system, liquid seal, gas seal, etc.
- Other requirements of customer
Main Features
Excellent corrosion resistance
Stainless steel, anti-corrosion alloy or anti-corrosion coating is adopted for the parts requiring contact with materials.
Wide application scope
It can be used for the separation of not only suspensions containing solid particles but also fibrous materials.
Manual discharging for better grain protection
Multiple safety protections
Nitrogen protection system, liquid seal, gas seal, overvibration protection, cover opening protection, overload protection, electromagnetic interlocking, etc.
