Vertical Small Manual 250kg Top Discharge Centrifuge 15kW With Halar Coating
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | PSB1000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 60 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| Basket Diameter(mm): | 1000 | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Top Discharge | Machine Control: | PLC Control |
| Basket Volume(L): | 200 | Operate: | Manual Batch Operating |
| Rotating Speed Control: | Frequency Converter | Dimension(mm): | 1970*1400*1500 |
| High Light: | 250kg Top Discharge Centrifuge,250kg vertical centrifuge machine,Top Discharge Centrifuge 15kW |
||
Product Description
PSB Vertical Easy To Operate Small Manual Top Discharge Basket Separation Machinery With Halar Coating
The PSB/PBZ series are enclosed manual top discharge and filtration centrifuges designed in line with the GMP standards and environmental protection requirements, which can be used for separating a wide range of materials. This product is highly applicable to the separation of various suspensions and fibrous materials with high temperature, strong viscosity and small particle sizes (minimum size of 1μm). Characterized by high separation factor, simple structure and high performance, the PBZ300 and 450 products are commonly selected as testing machines by various research institutions.
Main Features
- Big hinged cover, feeding pipe, washing pipe, observation glass and light.
- Automatic CIP system cleans the internal surface of the case, the basket and liquid slot to meet the clean requirement in accordance with GMP standards.
- Wide range of applications. No damage to the particle shape.
- Inverter start-up, smooth starting, adjustable relative centrifugal force.
- Tightness structure with silicone rubber or fluoroelastomers seals. Nitrogen protection system (optional) is for anti-explosion applied to poisonous, flammable and explosive environment.
PSB lined with PE PSB lined with HL
PSB
Technical Parameters
| Items | Models |
| PSB1000 | |
| Basket Diameter(mm) | 1000 |
| Effective Basket Height(mm) | 520 |
| Basket Volume(L) | 200 |
| Max. Capacity(kg) | 250 |
| Max. Speed(r/min) | 1200/1400 |
| Max. Separation Factor | 805/1096 |
| Motor Power(kw) | 11/15 |
| Dimension(mm) | 1970*1400*1500 |
| Weight(kg) | 2400/2600 |
