Chemical Processing Four Point Top Discharge Centrifuge 400L Basket Centrifuge
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | PSB1250 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | To be negotiated |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 65 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Top Discharge | Basket Volume(L): | 400 |
| Max. Capacity(kg): | 500 | Operate: | Manual Batch Operating |
| Max. Separation Factor: | 700/1007 | Weight(kg): | 3800/4800 |
| High Light: | Four Point Top Discharge Centrifuge,400L Basket Centrifuge,Top Discharge Centrifuge 400L |
||
Product Description
PSB Small Manual Vertical Chemical Processing Four Point Top Discharge Centrifuges Basket Centrifuges
Technical Parameters
| Items | Models |
| PSB1250 | |
| Basket Diameter(mm) | 1250 |
| Effective Basket Height(mm) | 630 |
| Basket Volume(L) | 400 |
| Max. Capacity(kg) | 500 |
| Max. Speed(r/min) | 1000/1200 |
| Max. Separation Factor | 700/1007 |
| Motor Power(kw) | 18.5/22 |
| Dimension(mm) | 2550*1800*1780 |
| Weight(kg) | 3800/4800 |
Main Features
- In compliance with the GMP standards: enclosed structure designed to effectively avoid contamination of materials. Configured with CIP online cleaning system to realize all-around cleaning.
- Wide opening structure designed for easier discharging and replacement of the filter bag.
- Small floor covering area, easy maintenance, low failure rate and long service life.
- High separation factor designed for better separation effect.
- Light in structure, simple in operation, low in gravity center, small in vibration and stable in operation.
- Grains less prone to breakage, with a wide scope of application.
- Multiple safety protection configurations, variable frequency control to realize stepless regulation of speed.
PSB lined with PE PSB lined with HL
SERVICE WARRANTY
Huada has Long tradition customer service, we always try our best.
Presale consulting - sales staff and sales engineers provide relevant technical advice specific to demands proposed by customers. Technical experts in application can provide technical support where necessary.
Type selection - centrifuge type selection is crucial and decides separation process feasibility, safety, product quality, yield, operation cost, etc. also, it a crucial impact on Infrastructure projects, equipment investment and environmental protection, etc.
For particular separation process requirements, we must totally understand physical and chemical properties of the material. Under the premise of meeting anti-corrosion and anti-explosion requirements (i.e. safety requirements). we can realize filtration and separation requirements and at the same time fully consider the automation, running cost and other factors . Our experts in application technology can put forward the corresponding proposal for specific operating conditions and effectively communicate with your process/ equipment, personnel to ensure reasonable, advanced and economical type selection
Laboratory test - Making laboratory analysis on separation characteristics of the material to provide the basis for type.
Small batch test - After preliminary type selection, simulation separation test can be carried out for small batch of verification machines to obtain relevant separation data and to provide the basis for separation process section design. This can be made in test workshop of Huada or can be made at place designated by the customer with vehicle-mounted test unit provided.
Equipment layout and Installation guide - providing centrifuge and system layout guided, installation and operation guide, in order to meet safety, use and maintenance requirement.
Debugging – During commissioning, providing site guidance of the service engineers and determining the corresponding operation parameters, to meet the separation requirements.
