Dual Phase Steel 2205 Vertical Centrifuge Machine For Agricultural Chemicals
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | PSB/PBZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD4000-20000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 60 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Top Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Manual Batch Operating | Rotating Speed Control: | Frequency Converter |
| Online Washing System: | Optional | ||
| High Light: | Steel 2205 vertical centrifuge machine,Steel 2205 Basket Centrifuge,vertical centrifuge machine Agricultural Chemicals |
||
Product Description
CE and ATEX Certifiied, GMP and cGMP Compliant. Validation Documents like OP, IQ, PQ & DQ provided. We are one of the largest Manufacturer and Exporter of Centrifuge Machine, CGMP Centifuge Machine,Centrifuge machines are available in various types like Bottom Discharge Centrifuge, Bag Lifting Centrifuge, Pharma Peeler Centrifuge and in various sizes like 12 inch, 24 inch, 36 inch, 48 inch dia customization can also be done. Our Well Engineered centrigue are supplied worldwide with all document required for GMP, USFDA approval. CE and ATEX Certifiied, GMP and cGMP Compliant. Validation Documents like OP, IQ, PQ & DQ provided.
- Special Characteristics of our Bottom Discharge Type Centrifuges
- Large Central Opening enables complete removal of scrapped solids/ cake
- Comparatively increased production due to process automation
- Toxic /hazardous material can be safely handled
- No Cake spillage
- No human contact between product & operator during operation
- Sturdy design & construction as per cGMP norms.
- Four point suspension type which requires negligible Foundation
- Centrifuge manufactured as per international standards with inertia platform
- & AntiVibration mounts to ensure smooth operation.
- Vapour Tight Arrangement
- Nitrogen purging system for Basket & bearing housing/ casing
- Safety Device such as Zero Speed Lock for the Centrifuge cover.
- Full validation services available including DQ, IQ/OQ, FAT / SAT protocols.
- cGMP construction for Pharmaceutical Models.
- Process Operation can be completely automated with PLC
- Heel Removal system
- Fully opening Outer case/ Body with CIP cleaning
- Variable Frequency Drive with the Dynamic Braking System
- Cake thickness monitor system.
- Excess Vibration Monitoring & Tripping system
- Fume Tight construction
- High Speed RPM for Basket for special application
MOC
All Stainless Steel/ Hastelloy construction with Contacts / vapour parts in 304/ 316 / 316L built to Custom requirement.
All Process contact surfaces finished with corrosion-resistant fluro-polymer coatings / Lining such as Halar (ECTEE), Teflon (PFA)
Technical Parameters
| Items | Models | |||||
| PSB600 | PSB800 | PSB1000 | PSB1200 | PSB1250 | PSB1500 | |
| Basket Diameter(mm) | 600 | 800 | 1000 | 1200 | 1250 | 1500 |
| Effective Basket Height(mm) | 325 | 450 | 520 | 550 | 630 | 680 |
| Basket Volume(L) | 47 | 120 | 200 | 270 | 400 | 555 |
| Max. Capacity(kg) | 70 | 150 | 250 | 340 | 500 | 700 |
| Max. Speed(r/min) | 1600/1800 | 1500 | 1200/1400 | 1100 | 1000/1200 | 850 |
| Max. Separation Factor | 860/1087 | 1007 | 805/1096 | 812 | 700/1007 | 606 |
| Motor Power(kw) | 3/4 | 7.5 | 11/15 | 15 | 18.5/22 | 30 |
| Dimension(mm) | 1470*990*1150 | 1730*1200*1320 | 1970*1400*1500 | 2300*1550*1500 | 2550*1800*1780 | 2750*2200*1750 |
| Weight(kg) | 1000/1200 | 1500 | 2400/2600 | 3000 | 3800/4800 | 6200 |
| Items | Models | |
| PBZ300 | PSB450 | |
| Basket Diameter(mm) | 300 | 450 |
| Basket Volume(L) | 5 | 20 |
| Max. Capacity(kg) | 7.5 | 30 |
| Max. Speed(r/min) | 2825 | 1900 |
| Max. Separation Factor | 1340 | 910 |
| Motor Power(kw) | 1.1 | 1.5 |
| Dimension(mm) | 605*605*830 | 800*800*1000 |
| Weight(kg) | 200 | 300 |
PSB lined with PE PSB lined with HL
PSB PBZ
