Steel 2507 1100rpm Top Discharge Centrifuge For Intermediate Pharmaceutical Products
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | PSB/PBZ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD4000-20000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 60 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| Type: | Separation Equipment | Centrifugal Type: | Basket Centrifuge |
|---|---|---|---|
| Discharge: | Bag Top Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Manual Batch Operating | Rotating Speed Control: | Frequency Converter |
| Online Washing System: | Optional | ||
| High Light: | 1100rpm Top Discharge Centrifuge,1100rpm basket centrifuge machine,Steel 2507 Top Discharge Centrifuge |
||
Product Description
High Lights of this basket filtering centrifuge,
1. It adopts plate and high viscosity damper shock absorber, no need of concete foundration, easy to operation.
2. The drum, housing and foundation all with polish process, all fasten parts are stainless steel, and seal parts are silicone
rubbers.
3. The whole machine is in the line with the GMP requirments.
4. Also it is with good seal, explosive-proof and cleaness.
Technical Parameters
| Items | Models | |||||
| PSB600 | PSB800 | PSB1000 | PSB1200 | PSB1250 | PSB1500 | |
| Basket Diameter(mm) | 600 | 800 | 1000 | 1200 | 1250 | 1500 |
| Effective Basket Height(mm) | 325 | 450 | 520 | 550 | 630 | 680 |
| Basket Volume(L) | 47 | 120 | 200 | 270 | 400 | 555 |
| Max. Capacity(kg) | 70 | 150 | 250 | 340 | 500 | 700 |
| Max. Speed(r/min) | 1600/1800 | 1500 | 1200/1400 | 1100 | 1000/1200 | 850 |
| Max. Separation Factor | 860/1087 | 1007 | 805/1096 | 812 | 700/1007 | 606 |
| Motor Power(kw) | 3/4 | 7.5 | 11/15 | 15 | 18.5/22 | 30 |
| Dimension(mm) | 1470*990*1150 | 1730*1200*1320 | 1970*1400*1500 | 2300*1550*1500 | 2550*1800*1780 | 2750*2200*1750 |
| Weight(kg) | 1000/1200 | 1500 | 2400/2600 | 3000 | 3800/4800 | 6200 |
| Items | Models | |
| PBZ300 | PSB450 | |
| Basket Diameter(mm) | 300 | 450 |
| Basket Volume(L) | 5 | 20 |
| Max. Capacity(kg) | 7.5 | 30 |
| Max. Speed(r/min) | 2825 | 1900 |
| Max. Separation Factor | 1340 | 910 |
| Motor Power(kw) | 1.1 | 1.5 |
| Dimension(mm) | 605*605*830 | 800*800*1000 |
| Weight(kg) | 200 | 300 |
Features of Vertical Bag-Lifting Top Discharge Basket Centrifuge:
1, Inverter start-up, smooth starting, adjustable relative centrifugal force.
2, Discharge cake by lifting out filter cloth is highly efficient with low labour intensity; No damage to the particles; Wide range of applications.
3, Well-designed structure and polished surface leaves no residual heel. With big hinged cover, it is easy to clean the gap between the case and the basket.
4, Overall welding structure between the base and the case ensures high carrying strength.
5, Platform base design lowers the center of gravity and requires minimum installation space. The platform base can be used for operation platform.
6, Liquid-damping vibration isolators, simplify the routine maintenance.
7, Big hinged cover, feed pipe, wash pipe, observation glass and light.
8, Automatic CIP system cleans the internal surface of the case, the basket and liquid slot to meet the clean requirement in accordance with GMP standards.
For the corrosive liquid material, the parts contacted liquid can be Stainless steel lined with PTFE.
PSB lined with PE PSB lined with HL
PSB PBZ
